AbrasivesSKU MW776

5" Grinding Disc - Steel & Stainless Steel

$2.59

CAD · Taxes and shipping calculated at checkout

  • Fast stock removal: aggressive aluminum oxide grain for heavy grinding on steel and stainless
  • Stainless-ready option: Sonnenflex Silverstar is made in Europe to EN12413 / AS1788.1 for steel and stainless
  • Type 27 depressed center: clearance for flat and low-angle grinding, weld blending and bevelling
  • 1/4" thick, fiberglass reinforced: long life and stability under heavy pressure
Thickness: 1/4"
Brand: Sonnenflex Silverstar
Type: Type 27 Depressed

905 919 1177
  • Ships Canada-wide from our Toronto warehouse
  • Canada-wide shippingTracked delivery to shops and job sites
  • Toronto showroomSee it in person, or collect at the counter
  • Expert supportTalk to people who weld, not a script
  • Secure checkoutEncrypted payment through Shopify

Overview

5" Steel & Stainless Steel Grinding Disc – Type 27

These 5" (125 mm) Type 27 grinding discs are built for fast, heavy stock removal on carbon steel, mild steel and stainless steel. Welders, fabricators and maintenance crews use them for weld removal, bevelling and surface prep. They are 1/4" thick for long disc life and fiberglass reinforced for stability and safety at full grinder speed.

Select thickness, brand and type above. Available from Sonnenflex Silverstar and Karbosan. Ships across Canada from MapleWeld, or pick up at our North York, Toronto showroom.

Key Features

  • Fast stock removal: aggressive aluminum oxide grain for heavy grinding on steel and stainless
  • Stainless-ready option: Sonnenflex Silverstar is made in Europe to EN12413 / AS1788.1 for steel and stainless
  • Type 27 depressed center: clearance for flat and low-angle grinding, weld blending and bevelling
  • 1/4" thick, fiberglass reinforced: long life and stability under heavy pressure
  • Universal fit: 7/8" arbor fits standard 5" angle grinders (DeWalt, Milwaukee, Makita, Bosch, Metabo)

Applications

  • Weld removal and bead grinding (MIG, TIG, stick, flux-core)
  • Pipe and plate bevelling and weld prep
  • Removing mill scale, rust and slag
  • Structural steel, railing, tank and equipment fabrication
  • Maintenance, repair and general shop work

Technical Specifications

Diameter 5" (125 mm)
Thickness 1/4" (6 mm)
Arbor / Bore 7/8" (22.23 mm)
Disc Type Type 27 Depressed Center
Application Steel & stainless steel grinding
Abrasive Aluminum oxide, resin-bonded, fiberglass reinforced
Brands Sonnenflex Silverstar and Karbosan
Tool 5" angle grinder

Part Number & Option Reference

SKU Thickness Brand Type Price
MW776 1/4" Sonnenflex Silverstar Type 27 Depressed $2.59 CAD
MW910560 1/4" Karbosan Type 27 Depressed $2.99 CAD

Buy Steel & Stainless Grinding Discs in Canada

MapleWeld (Maple Industrial Products Inc.) is a Canadian welding supply company based in North York, Toronto, Ontario. We ship abrasives and welding consumables coast to coast and serve walk-in customers from across the GTA. Business accounts, volume pricing and product samples are available for fabrication shops, contractors and maintenance departments.

Related Products

4.5" Steel & Stainless Steel Grinding Disc | 7" Steel & Stainless Steel Grinding Disc | Silverstar Flap Discs – Steel & SS | Silverstar Cutting Discs – Type 27 | Twist Knot Wire Wheel | All Grinding Discs | Abrasives

Specifications

5" Grinding Disc - Steel & Stainless Steel - specifications
Product typeAbrasives
Thickness1/4"
BrandSonnenflex Silverstar, Karbosan
TypeType 27 Depressed
Diameter5" (125 mm)
Thickness1/4" (6 mm)
Arbor / Bore7/8" (22.23 mm)
Disc TypeType 27 Depressed Center
ApplicationSteel & stainless steel grinding
AbrasiveAluminum oxide, resin-bonded, fiberglass reinforced
BrandsSonnenflex Silverstar and Karbosan
Tool5" angle grinder

Sizes & pricing

Every option with its part number and price. Select one to load it into the cart above.

Option SKU PriceSelect
1/4" / Sonnenflex Silverstar / Type 27 Depressed MW776$2.59
1/4" / Karbosan / Type 27 Depressed MW910560$2.99

Frequently asked questions

What is the best 5" grinding disc for steel and stainless steel?

For mixed shop work, a contamination-free disc rated for both steel and stainless steel (inox) is the safest choice. Sonnenflex Silverstar is made in Europe to EN12413 and suitable for both. Karbosan offers a value option for general metal grinding. Keep separate discs for stainless steel to avoid cross-contaminating it with carbon steel.

Why use a separate disc for stainless steel?

A disc that has touched carbon steel carries iron particles. If you then grind stainless with it, that iron embeds in the surface and causes rust spots (free-iron contamination). Use stainless-rated, iron- and sulfur-free discs, and dedicate them to stainless work.

What does Type 27 depressed center mean?

Type 27 discs have a recessed center hub, so the grinder's nut sits below the grinding face. That lets you grind flat or at a 15–30 degree angle for weld removal, blending and bevelling without the nut touching the work.

Will this 5" disc fit my angle grinder?

Yes, if your grinder takes 5" (125 mm) discs. The standard 7/8" (22.23 mm) arbor fits DeWalt, Milwaukee, Makita, Bosch, Metabo and other common angle grinders. Always match the guard to the disc size and never exceed the disc's maximum RPM.

Can I cut with a grinding disc?

No. A 1/4" Type 27 grinding disc is designed for side grinding only. For cutting, use a thin cutting disc (Type 1 or Type 27 cut-off wheel). Using a grinding disc to cut can overload it and cause breakage.

Do you ship grinding discs across Canada?

Yes. MapleWeld ships across Canada, including Ontario, Quebec, British Columbia, Alberta, Manitoba, Saskatchewan and the Atlantic provinces. Prices are in Canadian dollars, and volume pricing is available for fabrication shops and contractors.

Can I pick up grinding discs in Toronto or the GTA?

Yes. Visit our North York, Toronto showroom, which serves the GTA including Vaughan, Mississauga, Brampton, Markham, Scarborough, Etobicoke and Richmond Hill. Contact us to confirm stock or to open a business account.

How do I use a grinding disc safely?

Wear a face shield over safety glasses, hearing protection and gloves. Keep the guard on. Inspect the disc for cracks before mounting, run the grinder briefly before touching the work, and grind at 15–30 degrees with moderate pressure. Replace the disc when it wears to the label.
