Overview
MapleWeld E40 Dirty Cast Iron Stick Welding Electrodes
MapleWeld E40 ensures flawless cast iron welding with a nickel-cored electrode and specialized coating, delivering pore-free welding on grey and malleable cast iron — even on surfaces contaminated with oil. The pulsating welding technology alternates between a heat-generation phase and a droplet-projection phase, burning out oil and grease for effective slag removal while giving superior control over porosity. Controlled heat input allows a slower cooling rate on the first pass for a soft, machinable deposit without undercutting, and the all-positional design works with both A.C. and D.C. welding.
Key Features
- Nickel-cored electrode with specialized coating for pore-free welds
- Effective on grey and malleable cast iron, even oil-contaminated surfaces
- Pulsating arc burns out oil/grease and controls porosity
- Controlled heat input for a soft, machinable, undercut-free deposit
- All-positional welding, compatible with A.C. and D.C.
- Five rods per telescopic translucent plastic case
Applications
Ideal for welding cast iron requiring leak-tight, machinable results — including cracked motor blocks, pump housings, gear wheels, rebuilding lathe beds, and valve seats.
Technical Specifications
| AWS Classification | E40 (nickel cored) |
| Welding Process | SMAW (Stick), A.C. or D.C. |
| Tensile Strength | Rm >320 N/mm² (46 ksi) |
| Elongation | A5 >18% |
| Hardness | 130–160 HB |
| Rod Length | 12" |
| Package | 5 rods in telescopic translucent plastic case, 35x3x3cm, 140g |
| Available Diameters | 3/32" (2.5mm), 1/8" (3.2mm) |
Part Number & Size Reference
| 1/8" (3.2mm) – SKU MWE4032 – $24.47 CAD |
| 3/32" (2.5mm) – SKU MWE4025 – $25.32 CAD |
Other Products
Specifications
| Brand | MapleWeld |
|---|---|
| Size | 1/8 inch (3.2mm), 3/32 inch (2.5mm) |
| Shipping weight | 0.14 kg (selected option) |
Sizes & pricing
Every option with its part number, price and stock. Select one to load it into the cart above.
| Option | SKU | Price | Stock | Select |
|---|---|---|---|---|
| 1/8 inch (3.2mm) | MWE4032 | $24.47 | In stock | |
| 3/32 inch (2.5mm) | MWE4025 | $25.32 | In stock |
Not sure this is the right part?
Tell us the machine, the material and the job. A welding specialist - not a call centre - will confirm fit and pricing, including volume and trade quotes.
