MapleWeldWelding HelmetsSKU MWAV60

MapleWeld AeroView 60 Auto-Darkening Welding Helmet – Fixed Shade 11, 1/1/1/2 Optical Class

$59.00

CAD · Taxes and shipping calculated at checkout

  • Fixed DIN 11 dark shade: Nothing to set. Shade 11 is the AWS F2.2 suggested shade for MIG and flux-core at 60–160 A and exceeds the DIN 8 minimum for Stick in the same range.
  • 1/1/1/2 optical class: Top marks for optical quality, light diffusion and shade uniformity for a clear, low-distortion view of the joint.
  • 0.3 ms light-to-dark switching: The filter darkens the instant the arc strikes, then returns to a clear DIN 3 view 0.1–0.8 s after the arc stops.
  • Permanent UV/IR protection: Blocks harmful UV and IR radiation up to DIN 16 whether the filter is light, dark or switched off.

905 919 1177
  • Free shipping from $100–$250 depending on your province (before taxes) – ships Canada-wide from Toronto
  • Free shipping from $100Province-based flat rates, tracked delivery to shops and job sites
  • Toronto showroomSee it in person, or collect at the counter
  • Expert supportTalk to people who know, not a script
  • Secure checkoutEncrypted payment through Shopify

Overview

MapleWeld AeroView 60: Fixed Shade 11 Auto-Darkening Helmet for MIG & Stick Welding

The MapleWeld AeroView 60 is an entry-level, solar-powered auto-darkening welding helmet with a fixed DIN 11 dark shade, a DIN 3 light state and 1/1/1/2 optical class clarity. The filter darkens in 0.3 ms when the arc strikes and blocks UV/IR radiation up to DIN 16 at all times, making it a no-settings hood for MIG, flux-core and Stick welding.

It suits hobby welders, farm and maintenance shops, and anyone who needs a dependable spare helmet. The lightweight polypropylene shell resists spatter and impact, the 90 × 35 mm (3.54 × 1.38 in) window keeps the puddle in view, and the solar-plus-lithium power system switches on and off by itself.

Key Features

  • Fixed DIN 11 dark shade: Nothing to set. Shade 11 is the AWS F2.2 suggested shade for MIG and flux-core at 60–160 A and exceeds the DIN 8 minimum for Stick in the same range.
  • 1/1/1/2 optical class: Top marks for optical quality, light diffusion and shade uniformity for a clear, low-distortion view of the joint.
  • 0.3 ms light-to-dark switching: The filter darkens the instant the arc strikes, then returns to a clear DIN 3 view 0.1–0.8 s after the arc stops.
  • Permanent UV/IR protection: Blocks harmful UV and IR radiation up to DIN 16 whether the filter is light, dark or switched off.
  • Solar power + replaceable 3 V lithium battery: Fully automatic on/off, so there is no switch to forget.
  • Lightweight polypropylene (PP) shell: High-impact shell resists spatter, heat and shop drops while keeping neck strain down on long jobs.
  • Rated for cool shops: Operates from -5°C to +55°C and stores from -10°C to +70°C.

Technical Specifications

Brand / Model MapleWeld AeroView 60
Product type Auto-darkening welding helmet, fixed shade
Recommended processes MIG/MAG, flux-core (FCAW), Stick (SMAW)
Light state DIN 3
Dark state DIN 11 (fixed)
Optical class 1/1/1/2
Viewing area 90 × 35 mm (3.54 × 1.38 in)
Filter cartridge size 110 × 90 × 9 mm (4.33 × 3.54 × 0.35 in)
Switching time (light to dark) 0.3 ms
Delay time (dark to light) 0.1–0.8 s
UV/IR protection Up to DIN 16, at all times
Power supply Solar cells + 1 × replaceable 3 V lithium battery
Power on/off Fully automatic
Shell material Polypropylene (PP)
Operating temperature -5°C to +55°C
Storage temperature -10°C to +70°C

Shade Selection Guide

How the AeroView 60's fixed DIN 11 lens matches common welding and cutting jobs:

Process Current Suggested shade* AeroView 60 (fixed DIN 11)
MIG / flux-core 60–160 A 11 Yes, exact match
MIG / flux-core 160–250 A 12 Meets the DIN 10 minimum; DIN 12–13 is more comfortable
Stick (SMAW) 60–160 A 10 Yes
Stick (SMAW) 160–250 A 12 Meets the DIN 10 minimum
TIG (GTAW) 50–150 A 12 Meets the DIN 8 minimum; no TIG amperage rating published
Plasma cutting 20–60 A 5–6 No, too dark to follow the cut
Grinding N/A Clear / grind mode No grind mode; wear a face shield

*Suggested shades from the AWS F2.2 lens shade selector. Never use a shade lighter than the minimum for your process; start darker and go lighter until you can see the weld zone clearly. Follow your workplace welding safety program (CSA W117.2 in Canada).

Which MapleWeld Auto-Darkening Helmet Is Right for You?

Side-by-side specs for the MapleWeld AeroView, NovaSight, ClariView, ArcDuty and ProDuty auto-darkening welding helmets:

Model Dark shade (light state) Viewing area Switching speed Best for
AeroView 60 (this helmet) DIN 11 fixed (DIN 3) 90 × 35 mm 0.3 ms Budget MIG, flux-core & Stick
MapleWeld NovaSight 55 DIN 9–13 (DIN 4) 93 × 43 mm 0.04 ms MIG, Stick, TIG from 10 A; external dial, grind mode
MapleWeld ClariView 80 DIN 5–9 / 9–13 (DIN 4) 100 × 60 mm 0.2 ms Large view; plasma cutting + MIG, TIG, Stick
MapleWeld ArcDuty 90 DIN 5–9 / 9–13 (DIN 4) 100 × 60 mm 0.2 ms Large view, 3-step delay; plasma + MIG, TIG, Stick
MapleWeld ProDuty 94 DIN 5–8 / 9–13 (DIN 4) 100 × 50 mm 0.04 ms 4 sensors, grind mode, TIG from 5 A

Frequently Asked Questions

What shade is the MapleWeld AeroView 60 welding helmet?

A fixed DIN 11 dark shade with a DIN 3 light state. UV/IR protection is permanent up to DIN 16, so your eyes are covered even before the filter darkens.

Is a shade 11 welding helmet good for MIG and Stick welding?

Yes, for most garage and shop work. The AWS F2.2 shade selector suggests shade 11 for MIG and flux-core at 60–160 A and shade 10 for Stick in the same range. Above about 160 A, DIN 11 still meets the minimum, but a variable DIN 9–13 helmet such as the NovaSight 55 lets you go darker.

Can I use the AeroView 60 for TIG welding or plasma cutting?

It is not the right tool for either. DIN 11 is too dark to follow a plasma cut (20–60 A cutting calls for shade 5–6), and no TIG amperage rating is published. For TIG, choose the ProDuty 94 (rated from 5 A) or NovaSight 55 (from 10 A); for plasma cutting, the ClariView 80, ArcDuty 90 or ProDuty 94.

What does optical class 1/1/1/2 mean on a welding helmet?

It is the four-part rating used by the EN 379 standard: optical quality (distortion), light diffusion, uniformity of shade across the lens and angle dependence. Each is scored from 1 (best) to 3, so 1/1/1/2 means top marks in the first three categories and class 2 for viewing at an angle.

Does the AeroView 60 need batteries?

It runs on solar cells backed by one replaceable 3 V lithium battery, and powers on and off automatically.

Will the AeroView 60 work in a cold shop?

It is rated to operate from -5°C to +55°C and can be stored from -10°C to +70°C. In colder shops, keep the helmet in a heated area between jobs, because auto-darkening filters respond more slowly when chilled.

Can I grind with the AeroView 60?

It has no grind mode, so grinding sparks can trigger the filter. For grinding, wear a clear face shield such as the Fibre-Metal FMF400CSA face shield.

Buy Online or Pick Up in North York (Toronto)

Sold and supported by MapleWeld, the Canadian welding supply store of Maple Industrial Products Inc. Order online for delivery anywhere in Canada, or pick up at 3625 Weston Rd Unit 10, North York, ON M9L 1V9. Questions? Call 905-919-1177 or email orders@mapindpro.com.

  • Shipping: Orders process in 1–3 business days; delivery then takes 1–2 days in the GTA, 3–4 days in the rest of Ontario and 3–6 days to Western, Quebec and Eastern Canada.
  • Free shipping: On qualifying Canadian orders before tax, excluding heavy, oversized and dangerous goods (see our shipping policy).
  • Returns: 30-day returns on unused items in original packaging (see our refund policy).

Part Number & Size Reference

Model
MapleWeld AeroView 60
